Yellow-Green 122x32 small lcd module for instruments

FOB Reference Price:Get Latest Price
US $1-11.5 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
200000 Piece/Pieces per Month
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Ruishine
Model Number:
RS-12232F001
Type:
Graphic
Display Type:
STN YELLOW-GREEN POSITIVE LCD
Assembly:
COB
Controller IC:
ST7920 OR EQUIV
Polarizer:
Transflective
Backlight:
YELLOW-GREEN, VLED=5.0V,ILED<=20mA
Connector:
Zebra
Packaging & Delivery
Packaging Details
Wrapped in air bubble film and covered by anti-static trays, and then packed in suitable cartons. The packing is able to withstand rough handling. External carton size: 390x350x490mm
Delivery Time
5--25 working days

Specifications

1)YELLOW-GREEN POSITIVE,122x32 small lcd module
2)Easy to be customized based on your request
3)High stability and quality



Product Description



Model NO.:12232F001
Outline Size:70.0x36.0x12.5mm(with backlight)
View Area:60.0x18.0mm
Display Type:STN/Y-G/TRANSFLECTIVE POSITIVE
Viewing Direction:6:00 O'Clock
Operation Voltage:VLCD=4.5 V
Drive Method:1/32 Duty; 1/5 Bias; VDD=5.0v
Controller IC:ST7920 OR EQUIV
Backlight type:YELLOW-GREEN, VLED=5.0V,ILED<=20mA
Display Dots Matrix:122X2(16+16) small lcd module
Operating Temp:–20ºC TO +70ºC
Storage Temp:–30ºC TO +80ºC





Packaging & Shipping

 Packaging Detail: Wrapped in air bubble film and covered by anti-static trays, and then packed in suitable cartons. The packing is able to withstand rough handling. External Carton size: 390x350x490mm

 Delivery Detail: 5~25 working days after payment confirmed.

  Shipping:  Express way as DHL,Fedex,EMS,UPS, air shipping, sea shipping, Any shipping method you prefer.

Our Services



Customize new produc





Quality assurance

    In compliance with ISO9001:2008 Quality Management System, and always focus on product quality, customer service. Before all products sold to the client, they must go through strict testing by QC department.
