Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Ruishine
  • Model Number: S0802D
  • Type: Character
  • Display Type: STN BLUE NEGATIVE
  • Assembly: COB
  • Controller IC: ST7066U Or Equiv
  • Polarizer: Transmissive
  • Backlight: White LED,VLED=3.3V

Packaging & Delivery

Packaging Details Wrapped in air bubble film and covered by anti-static trays, and then packed in suitable cartons. The packing is able to withstand rough handling. External carton size: 390x350x490mm
Delivery Time 5--25 working days

Specifications

1)display type: blue negative LCD dot matrix Display
2)08X2 dots matrix,
3)High quality,
4)pcba+IC+LCD panel perfect match







Product Description
Model NO.:0802D
Outline Size:54.6x27.5x14.0mm(with backlight)
View Area:37.7x15.7mm
Display Type:STN /BLUE /NEGATIVE, /TRANSMISSIVE
Viewing Direction:6:00 O'Clock
Operation Voltage:VOP=4.5 V
Drive Method:1/16 Duty; 1/5 Bias; VDD=3.3v
Controller IC:ST7066U Or Equiv
Backlight type:White LED,VLED=3.3V
Display Dots Matrix:08×2(5X8 Dots) LCD dot matrix Display
Operating Temp:0ºC TO +50ºC
Storage Temp:–10ºC TO +60ºC



PINSYMBOLFUNCTIONS
1VSSGND
2VDDPower supply for logic(+5.0v)
3V0Power supply for LCD
4RSRegister selection(H:Data registor; L:Instruction Registor
5R/WRead/Write selection(H:Read;L:Write)
6EEnable signal for chip
7DB0Data bus line
8DB1Data bus line
9DB2Data bus line
10DB3Data bus line
11DB4Data bus line
12DB5Data bus line
13DB6Data bus line
14DB7Data bus line
15LED APower supply fo backlight(+5.0V)
16LED KPower supply fo backlight(0V)






Packaging & Shipping

 Packaging Detail: Wrapped in air bubble film and covered by anti-static trays, and then packed in suitable cartons. The packing is able to withstand rough handling. External carton size: 390x350x490mm

Delivery Detail: 5~25 working days after payment confirmed.

   Shipping:  Express way as DHL,Fedex,EMS,UPS, air shipping, sea shipping, Any shipping method you prefer.



Our Services



Customize new produc





Quality assurance

  In compliance with ISO9001:2008 Quality Management System, and always focus on product quality, customer service. Before all products sold to the client, they must go through strict testing by QC department.
